5.98″ – 16:9 Windows 10 Rugged Handheld Terminal EM-I62

– 5.98″ 16:9 720×1280 IPS Capacitive touch screen
Windows 10
– USB2.0 OTG
– NXP NFC(13.56M)
– GPS navigation
– Rugged IP65 protection level
– High strength Glass Touch Panel
– MIL-STD-810G, CE, Battery: UN38.3, MSDS, IEC6213

Barcode Scanner

Optional Accessories

Product price
Additional options total:
Order total:
Category: SKU: EM-I62

Description

Functions

  • Support for Windows 10 system
  • Optional RFID Module
  • Integrated 3G all network communication, WiFi, Bluetooth and other communication modes
  • Equipped with 5000mAh large capacity wide temperature battery, the machine has a endurance of 6-8 hours
  • IP65 high protection level, in accordance with MIL-STD-810G
  • Support GPS, more accurate positioning
  • Equipped with front 2 million and rear 5 million pixel auto focus camera
  • Support 1D / 2D, NFC and other functional modules to meet the application needs of multiple industries

Additional information

Application

Delivery, Healthcare, Logistics, Retail, Transportation, Warehouse

GENERAL



CPU

Intel Atom® x5-Z8350

CPU Type

2M Cache, 1.44Ghz to 1.92 GHz

GPU

Intel® HD Graphics

Operating System

Windows 10 IOT 32bit

RAM

2GB DDR3L

ROM

32GB Emmc

Memory expansion

SDHC/SDXC max128G

Sensors

E-Compass, G-Sensor, Gyroscope

Buttons

Power
Volume +/-
HOME Key
Barcode Trigger x2

Notifications

Sound, vibration, LED prompt

Audio

Built-in 8Ω/0.8W Waterproof Speaker
Mic: Sensitivity:-42db, output resistance 2.2kΩ

Earphones Jack

∮3.5mm

Dimentions

185mm x 93mm x 20.7mm

Weight (with battery)

380g

CAMERA



Rear Camera

8.0MP

Front Camera

2.0MP

Focus mode

Autofocus

DISPLAY



Brightness

430 Nits

Screen Size

5.98"

Resolution

IPS 720×1280 720P

Touch Panel

5 points Capacitive, G+FF, Rigidity: above 7H-Anti-scratch

POWER



Battery Capacity

Li-Po 5000mAh / 3.7V

Charging

Input: 100~240VAC 50/60HZ Output: 5VDC 3A
Pogo Pins

Interface

Micro USB 2.0, OTG

CONNECTIVITY



WWAN

IC:H350_A30
WCDMA(900/2100MHz)
GSM(900/1800MHz)
HSDPA 7.2Mbps
HSUPA 5.76 Mbps

Bluetooth

BT4.2 (BLE)

WLAN

WIFI 802.11(a/b/g/n/ac) Frequency 2.4G+5.8G dual band WIFI intel 3165D2WG

GPS

U-blox NEO-7

NFC (Optional)

NXP NFC 13.56MHz support under ISO/IEC 14443A/14443B/15693/18092/mi-fare protocol
Card reading distance:4cm

1D Barcode Scanner (Optional)

Honeywell N4313
Optical resolution: 5mil, scan speed: 50times/s
Supportive code: UPC/EAN, Bookland EAN ,UCC
Coupon Code, ISSN EAN,
Code 128,GS1-128,ISBT 128,
Code 39
Trioptic
Code 39
Code 32
Code 93
Code 11

2D Barcode Scanner (Optional)

Honeywell N3680 hard decode
Optical resolution:5mil, scan speed:50times/s
Supportive decode: PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse, Maxicode, QR Code, MicroQR, QR Inverse, Aztec, Aztec Inverses, Han Xin, Han Xin Inverse

RFID (Optional)

Voltage:DC 3.5V – 5 V
Current:180mA
Supported protocol:EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C
Frequency:902Mhz – 928Mhz
Acceptance sensitivity:< -70dBm
Speed of card reading:> 50PCS/S
Interface:TTL Uart
Baud rate:115200 bps
Stable recognition distance 1.5M~2M

DURABILITY



Working Temperature

-10°C to 50°C

Storage temperature

-20 °C to 60 °C

Humidity

5%-95% (Non-Condensing)

Ingress protection

IP65

Drop test (Operating)

1.2m composite wood floors

Certifications

CE, NB, MIL-STD-810G, UN38.3, MSDS, IEC62133
