Conquest S16 Rugged Smartphone – Intrinsically Safe (ATEX)

Conquest S16 IP68 Rugged Mobile Phone 6.3″ Display Helio P90 Octa Core 8GB 256GB 48MP Cam Android 9 UV Detection Infrared Remote Control

Certifications: Zone 1, Div 2, Ex ib IIC T4 Gb/Ex tD A21 IP68 T135℃

Clear
Product price
Additional options total:
Order total:
Categories: , SKU: CQ-S16-EX

Description

Conquest Rugged phones is specializes in building highly durable smartphones for professionals or active people who need a handset that can survive a harsh lifestyle. Its products vary, going from feature phones that cover one’s basic modern needs to flagships that are both durable and affordable.Serving users of military police, public safety, petrochemical, coal and minerals, air transportation, rail transit, power and water conservancy, construction, forestry and fishery, disaster reduction and rescue, etc., providing all kinds of communication products, technical services and overall solutions required.

Additional information

Application

Mining, Oil & Gas, Rescue

Safety Rating

A21, Div2, Ex, Gb, ib, IIC, T135℃, t4, tD, Zone 1

DESIGN

Operating System

Android 9.0

Color

Gold, Red, Silver

Dimentions

170mm x 81mm x 14.9mm

Weight

308g

DISPLAY

Screen Size

6.3"

Resolution

IPS 1080×2280
Pixel density: 402ppi
Screen ratio: 19:9

Touch Panel

5 Points Capacitive

GENERAL

CPU

Helio P90 (MT6779)

CPU Type

64 bit – 2x 2.2GHz ARM Cortex-A75, 6x 2.0GHz ARM Cortex-A55

GPU

IMG 9XM-HP8 (PowerVR GM9446), 970MHz

RAM

8GB

ROM

128GB, 256GB

Memory expansion

TF card up to 2TB

Sensors

E-Compass, Fingerprint, G-Sensor, Gyroscope, Infrared, Light Sensor, Range Sensor

Notifications

Sound, vibration, LED prompt (Breathing Light)

Audio

Built-in 110d, 2.5 times the volume of regular phone with Smart PA amplifier.
Mic: Dual microphone noise cancellation

Earphones Jack

Type-C / Bluetooth

CAMERA

Rear Camera Type

Triple camera, 30fps, Face Detection

Rear Camera

16MP, 48MP, 5.0MP

Front Camera

16MP

Focus mode

PDAF (Phase Detection Auto-Focus)

POWER

Battery Capacity

Li-Po 6000mAh

Charging

9V / 2A
QI Wireless Charging 18W

Interface

Type-C
OTG
Magnetic Pins
Dock

CONNECTIVITY

SIM Quantity

Dual SIM

SIM Type

Nano SIM

WWAN

2G Bands: GSM 850/900/1800/1900MHz
3G Bands: TD-SCDMA 1880-1920(B39)/2010-2025(B34)MHz
WCDMA 850/900/1700/1900/2100MHz
4G Bands: TDD-LTE: 2500(B38)/1900(B39)/2300(B40)/2500(B41)MHz
FDD-LTE 700(B17&B12)/800(B20&B19)/850(B5)/900(B8)/1700(B4)/1800(B3)/1900(B2)/2100(B1)/2600(B7)MHz

WCDMA, GSM, FDD-LTE, TDD-LTE, TD-SCDMA

Bluetooth

BT5.0

WLAN

WIFI 802.11(a/b/g/n/ac) Frequency 2.4G+5.8G dual band WIFI

GPS

GPS, Glonass, Beidu, Galileo

NFC

Yes

FM Radio

Yes

DURABILITY

Working Temperature

-35℃ to +70℃

Storage temperature

-50 °C to 80 °C

Humidity

5%-95% (Non-Condensing)

Ingress protection

IP68

Certifications

MIL-STD-810G, GSM, CE, UN38.3, MSDS, IEC62133, ISO15693, ISO1443A/B

MISCELLANEOUS

Package Contents

1 x Conquest S16 phone
2 x Type-C USB cables
1 x User Manual
1 x SIM card pin
1 x Adapter
